Experience superior navigation performance with the YMZFPV M10-5883 GPS (10th gen). Fast positioning, high accuracy, and strong signal reception lets you stay on course in any environment. Take the worry out of navigation with this reliable, 10th-generation GPS.

Check out our otherGPSoptionsandthe rest of our YMZFPV Products

Features

• Based on the new generation of M10050 chip, this product has a fast speed for star search and high positioning accuracy.
• Using Nissan’s LNA amplifierandcustom the fine-tunedantenna of ceramic and three-frequency
• This product can support: GPS Galileo, BDS three kinds of satellite system positioning to meet the positioning needs of users in different countries and regions
• Built-in Flash chip, allowing you touse the U-CENTER software for personalized settings
• The onboard electronic compass provides accurate orientation
• The LED indicator of the side
• High safety, and the protection circuit is designed in 5V and GND
• The on-board farad capacitor can save the current satellite information for about 45-90min for a fast hot start

Specifications

• Model: M10-5883
• MCU-Ublox-M10050
• GNSS: GPS, Galileo, BDS
• Protocol Ublox
• Frequency: 5Hz (Max. 10Hz)
• Flash: Onboard FLASH (Modifiable)
• Tracking sensitivity: -167dBm
• Speed precision: 0.05m/s
• Maximum speed: 500m/s
• Maximum acceleration: 50000m
• Positioning accuracy: 1.5m CEP (ideal environment)
• Cold start: 26s
• Hot start: 1s
• Input voltage: 3.3V-5V
• Dimension: 29 x 29 x 8.4mm
• Weight: 12.8g

Includes

• 1xYMZFPV M10-5883 GPS w/Compass (10th gen)
