TrueRC in collaboration with Tiny Whoop, are pushing the limits of FPV technology with this one of a kind. The Smol is the lightest 5.8GHz CP antenna known to mankind. At a mere 0.25g, even the smallest aircraft will barely notice it! No compromise either, with same range as any of our other antennas.

Features

• Incredibly low weight of 0.25g (with 20mm u.fl)
• Excellent axial ratio and efficiency
• Same range as any full size/weight 5.8GHz CP antenna.

Specs:

• Gain:1.9dBic
• Polarization: RHCP or LHCP
• Cross-Polar Rejection: -10 to -20dB, (3.2%)
• Bandwidth: 5.6GHz-5.9GHz
• Radiation Efficiency: 98%
• SWR: <=1.5:1
• Weight: 0.25g

• Dimensions: 9.5mm dia. x 6.4mm height.
• Connector: U.FL

US. Pat. 10,804,618

Can. Pat. 2968566
