Introducing the SpeedyBee Bee35: the frame that combines the strength of aerospace-grade aluminum with the elegance of seamless engineering.

Note:

• BEE35 comes with a carbon fiber bottom plate.
• BEE35 PRO comes with an aluminum alloy heat sink bottom plate.

Check out our SpeedyBee Bee35Frame Parts Collectionand the rest of ourSpeedyBee Products!

Aerospace-grade Aluminum Front PlateThe aviation-grade aluminum headpiece provides excellent protection for the lens, and it is embedded with custom silicone damping material, resulting in effective anti-vibration performance for the lens. The GyroFlow effect is enhanced for better stability.

Open-source 3D printing schematics are available, enabling you to print them with different thicknesses to accommodate various lens installations –> Download

100% efficient heat dissipationWe have found that the O3 video transmitter shuts down due to high CPU temperatures during prolonged high-temperature operation. To address this issue, we have specially designed a 7075-T aerospace-grade aluminum component for the O3 video transmitter, doubling its heat dissipation efficiency! Additionally, it features 20×20 mounting screw holes, making it compatible with Link, TX800, and other 20-hole video transmitters.Custom-made aerospace-grade aluminum components.Specially designed to solve the TF card insertion issue of O3 without disassembly. Easily insert the card without any hassle. It also features a dedicated frequency position for O3 and Link video transmitters, making it super convenient for Type-C connection!

Two battery installation methods.Super convenient battery strap design allows for horizontal or vertical battery mounting.Super durable injection-molded ring.Made of high-strength imported composite material with built-in LED strip mounting groove.Compatible with flight towers.Supports installation of various flight towers and AIO (All-In-One) boards in sizes of 20×20, 25.5×25.5 (45 90), and 30.5×30.5.20-hole MINI flight tower Recommended (Perfect fit)
25.5-hole AIO flight controller Recommended (Perfect fit)
30.5-hole standard flight tower Not recommended
(Installation is compact and requires some hands-on skills)Multi-function antenna mount.Type-C adapter cable directly plugs into the flight controller without disassembling the aircraft.Quick Release SolutionOnly 6 screws are to be removed for freeing drone body and propeller guard.Detachable damping gimbal, Convenient for mounting different cameras with damping.

Download the Manual

Download the Lens Damping Files

Features:

• 1.Customized aluminum alloy front end to effectively protect unobstructed O3.
• 2.Customized silicone gel shock absorption for the O3 lens, eliminating jelly effect.
• 3.Customized aluminum alloy heat dissipation device at the bottom, seamlessly integrated with O3 and RunCam link transmission, while also facilitating Type-C and memory card insertion for convenient frequency adjustments.
• 4.Flight tower compatibility: Hole patterns for 2020mm/ 25.525.5mm/30.5*30.5mm.
• 5.Battery compatibility: Horizontal and vertical mounting design, eliminating concerns about difficult installation after zip tie breakage.
• 6.No need to disassemble for flight controller connection, supporting both Type-C and micro connectors for flight towers.
• 7.Highly durable injection-molded protective ring with built-in LED strip groove, facilitating LED strip installation.
• 8.Complete set of printed parts, including GoPro mount, 121GPS mount, multi-functional antenna mount, and T-shaped antenna holder.
• 9.Adjustable GPS mount compatible with both GPS and MASTER 5 V2 GPS mounts, with 121GPS mount included as standard.
• 10.Supports detachable shock-absorbing gimbal (not included in standard package).

Specifications:

• Wheelbase 153mm
• Top Plate Thickness 3.5mm
• Bottom Plate Thickness 2mm
• Camera Mounting Distance 19/20mm
• ESC/Motor Mounting Height 24mm
• Flight Stack Mounting Holes 20*20/25.5*25.5/30.5*30.5mm
• Video Transmitter Mounting Holes 20*20/25.5*25.5
• Propeller Size 90mm
• Motor Mounting Holes 12*12mm
• Weight 138g
• CNC Heat Sink 15g
• Camera Gimbal 28g
• Recommended Motor 1806/2004/2006
• Recommended KV 4S/2500-3500KV,6S/1800-2300KV
• Recommended Battery 900-1500mAh 4S/6S
