The SEQURE E70 G2 ESC features a high-performance STM32G071 processor compatible with BLHeli_32 and AM32 firmware, supporting 2-8S voltage input with a continuous current of 70A and peak up to 150A. It includes an integrated galvanometer for real-time telemetry of motor speed, temperature, and current. Equipped with premium high-power MOSFETs, it ensures efficient power conversion to extend flight time. Its multi-layer PCB with thick copper enhances current capacity and heat dissipation. Precise timing control delivers smooth, responsive ESC performance. The PWM frequency ranges from 16KHz to 128KHz, preventing step-out issues. The innovative angled soldering pads improve wiring safety and aesthetics, while the 30.5×30.5mm mounting hole spacing fits various frames for easy installation.

Package Includes:

1x SEQURE E70 G2 4 in 1 ESC

1x 30AWG 40mm reverse double plug SH1.0-8P cable

1x 30AWG 60mm single plug SH1.0-8P cable

2x 12AWG 100mm power cable (black/red)

1x XT60H-M black male connector

1x 35V 680UF solid capacitor

5x M3*8mm shock absorbing washer (black)
