The RUSH BLADE F722 Stack for theDJI Digital FPV Systemby RUSHFPV features theRUSH BLADE F722 Digital Flight Controller and RUSH BLADE 60A 3-6S BLHeli_32 4-in-1 ESC (Super Edition),which can handle up to 6S input voltage and push your FPV racer to the max.

SPECIFICATIONS

RUSHFPV RUSH BLADE F722 DIGITAL FLIGHT CONTROLLER FOR DJI DIGITAL FPV SYSTEM

• MCU: STM32 F722 RET6 216MHz
• GYRO: MPU6000
• Blackbox: 16Mb SPI Flash
• Input Voltage: 7-40V 3-8S LiPo
• BEC Output: 5V/5A 10V/3A
• Ports: 6 x PWM, 5 x UART, 1 x I2C
• LED: Supports WS2812 LED Strip
• Mounting Holes:30.5mm x 30.5mm
• Dimensions: 36.5mm x 38mm x 5.2mm
• Weight: 9.5g (Without Cables)
• Firmware Target: Rush_Blade_F7_HD

RUSHFPV RUSH BLADE 60A96KHZ 3-6S BLHELI_32 4-IN-1 ESC -SUPER EDITION

• Rated Current: 60A
• Peak Current: 80A
• Input Voltage: 3-6S Lipo
• MCU: F350 @ 168MHz
• PWM FREQ: 24-96KHz
• LED Color: Pink
• Weight16.5g
• Dimension: 45*36.5*7.5mm
• BL32 FW: RUSH_BLADE_SUPER

INCLUDES

• 1 xRUSHFPV RUSH BLADE F722 Digital Flight Controller For DJI Digital FPV System
• 1 x RUSHFPV RUSH BLADE 60A 3-6S BLHeli_32 4-in-1 ESC -Super Edition
