NewBeeDrone BDR Unicorn Edition Motors – 6mm Brushed Motors

The NewBeeDrone BDR Unicorn Edition Motors – 6mm Brushed Motors are designed to elevate your micro drone’s performance to new heights. These 6mm brushed motors combine smooth operation with powerful thrust, giving pilots the control and speed needed for both indoor and outdoor flight. The Unicorn Edition motors feature an exclusive design, offering not only reliable performance but also a unique aesthetic.

Whether you’re racing through tight spaces or performing freestyle tricks, these motors provide responsive throttle and enhanced agility. The Unicorn Edition motors are compatible with a variety of micro FPV drones, including NewBeeDrone’s popular AcroBee series, ensuring a seamless upgrade to your current setup.

Optimized for performance, the BDR Unicorn Edition Motors offer a balance of power and efficiency, making them perfect for beginner and experienced pilots alike. Upgrade your micro drone and experience the difference these 6mm motors bring to your flight.

Specifications:

UnicornEdition Motors

• KV: 25,500
• Speed: 93,000 RPM (@ 3.7V)
• Current Load: 1.0A (@ 3.7V, direct drive)
• Lifetime Rating: 4-5 hours
• No Load Current: 200 mA
• Start Torque: 22 g.cm
• Stall Current: 4500 mA
• Terminal Resistance: 0.7 Ohms
• Operating Voltage: 0.5 – 4.35 V

Dimensions:

• Can Diameter: 6mm
• Can Length: 17mm
• Shaft Diameter: 0.8mm
• Shaft Length: 5mm
• Weight: 2g
• Wire Length: 30mm
• Plug:Micro-JST-1.25

Package Includes:

• 4 NBD Unicorn motors (2 CW, 2 CCW)
