The MATEN 1.2G 2W VTX high-power image transmission newly developed by the GEPRC team is now officially released.Its performance is very powerful, with 4 adjustable power levels and a maximum power of up to 2000mW.The transmission signal is very stable and the penetration ability is excellent.

MATEN1.2G2WVTXuseshigh-strengthaluminumalloyCNCshelltoassistheatdissipation.Theuniqueappearancedesignstrongerimpactresistanceandbetterheatdissipationperformance.

ItsupportstheIRCTrampprotocolandcanusetheOSDtoquicklyadjustparameters.

Ithasawidevoltageinputof7-36Vandtemperaturecontrolprotectionfunctiontopreventoverheatingandburning. Support 30.530.5mm(M3)installationholeposition.

Warning:

• Install Antenna before use.
• To prevent overheating, provide constant airflow and a well ventilated environment. Install a cooling fan if operating in confined conditions.
• The 5V Output is for a Camera/Cooling Fan use only!Do not connect Power Input/Battery to 5V Out. Serious damage will occur to VTX.

Check out our Analog Video Transmitters Collection as well as the rest of our GEPRC Collection!

Features:

• Four levels of adjustable power, up to 2000mW, suitable for long distance flight
• optional channels
• Selected high strength aluminum alloy CNC shell, auxiliary heat dissipation
• Widevoltageinput,Supports7V-36VVoltageinput.
• One function buttons, two indicator lights, easy to control.
• VTX control protocol is IRC Tramp,supports OSD parameter adjustment.
• Temperature control protection function that can prevent high temperature burning
• Support30.530.5mm(M3)installationholeposition

Specifications:

• ModelGEPRCMATEN1.2G2WVTX
• Size36.436.4x7.4mm
• Mountinghole30.530.5mm(M3)
• Frequencyband1080MHz-1360MHz
• Channelcustomer9
• ChannelFrequency1080/1120/1160/1200/1240/1280/1320/1360/1220(MHz)
• Outputpower25mW/400mW/800mW/2000mW/Pitmode
• FrequencyStability100KHz(Typ.)
• Frequencyprecision200KHz(Typ.)
• S/N(Fo3MHz)>70dBc
• AntennaPort50Ohms
• InputvoltageDC7-36V2-8SBattery
• Outputvoltage5V@600mA
• ProtocolIRCTramp
• AntennainterfaceMMCX
• Cableinterfacesh1.256pin
• VideoformatPAL/NTSC
• OperatingTemperature-10~+60
• Weight14.5gVTXonly

Package Includes:

• 1xMATEN1.2G2WVTX
• 1xMMCXtoSMAinternalneedleconnector
• 1×1.2Gantenna(SMAinnerhole)
• 1xsh1.256PConnectingcable
• 5xM3*7screws
• 5xM3*8screws
• 5xM3x10hexagon
• 5xM3*5isolationcolumn
• 5xM3nylonnut
• 1 x product description
