This antenna is exceptionally powerful, extending your drone’s range and reducing interference and noise from other devices or networks.This is a dual band patch antenna designed to be used with the dji fpv goggles version 2 and the dji fpv drone now this antenna is designed to give you the best possible performance from this system. It offers an optimal connection from the DJI FPV Goggles V2 to the DJI FPV Drone, DJI Avata Drone, and DJI O3 Air Unit. Pilots have reported a reliable video connection of up to 9.63 miles (15.4 km). Manufactured in Los Angeles, California with the finest materials, this antenna is made in the USA.

Check out all out FPVTEC Products,FPV Receivers & Antennas, and ourDJI compatible gear!

Features

• Compatible with the DJI FPV Drone, Avata Drone, and DJI O3 Air Unit
• Low Loss Coaxial Cables – Rated up to 6 GHz
• Antenna mount fits the DJI FPV Goggles V2
• Solid video at 9.63 Miles / 15.4 km
• Extends the range of your drone
• Linear and Vertical Polarization
• High-Quality Material
• Made in the USA

Specifications

• Compatibility: DJI FPV Drone, DJI Avata Drone, and DJI O3 Air Unit
• Gain : 9dBi @ 5.8 GHz 6.5 dBi @ 2.4 GHz
• Antenna Mount: Fits DJI FPV Goggles V2
• Horizontal: 5.8 GHz: 55 2.4 GHz 75
• Vertical: 5.8 GHz: 65 2.4 GHz: 70
• Polarization: Linear, Vertical
• VSWR : 2.0:1
• Weight: 160g

Includes

• 1x FPVTEC Kaiju 5.8GHz / 2.4GHz Range Extender Dual Band Patch Antenna for DJI Goggles V2 – Linear / Vertical
• 1x 3D Printed Mount (Preassembled)
• 2x Low Loss Coaxial Cables
• 2x Precision Thumb Screws
• 4x Nano SMA Grips
