Check outFlyFishRC M8QMC-5883L GPS & Compass Module, which uses ublox 10th generation chip for staple positioning speed. With this quality made GPS you’ll experience a more stable connection. This new generation of GPSs have the ability to connect to more satellites simultaneously. This unit comes with a high sensitivity 18x18mm GPS patch antenna. It has aSH1.0-6Pin terminal design, so no soldering required!

Check out ourGPS selectionand all our FlyFishRC products!

Features

• 72 channel 10 Hz Refresh rate
• Built-in TCXO crystal and farad capacitor for faster hot start
• High sensitivity 18x18mm GPS patch antenna
• SH1.0-6Pin terminal design, no soldering required
• QMC5883L Magnetometer chip, Precise pointing

Specifications

• GPS module: FlyFishRC M8QMC-5883L GPS Module
• Frequencies: 72 channel
• Refresh Rate: 10 Hz
• Compass module: QMC5883L
• Baud Rate4800bps-115200bps (Default – 9600bps)
• Sensitivity: Tracking: -162dBm Capture: -160dBmCold Start-148dBm
  Accuracy: Horizontal <2.5m average), SBAS < 2.0m average, Timepulse: RMS 30 ns
• Cold start: <24s
• Hot start: <2s
• Maximum height: 50000m
• Maximum speed: 500 m/s
• Speed accuracy: 0.05 m/s
• Maximum acceleration: 4G
• Input Voltage: 3.3V-5Vcurrent 25mA
• Output Connector: SH1.0-6P
• Weight: 8.8g
• GPS pin definition: RX/TX UART
• Compass pin definition: SDA/SLA

Includes

• 1x FlyFishRC M8QMC-5883L GPS AND COMPASS MODULE
• 1 x SH1.0-6Pin Cable

• 1 x SH1.0 Connector

• 1 x GPS Manual

Wiring Diagram & Betaflight Configuration
