The FlyfishRC-M8QMC is a miniature, highly responsive, and user-friendly GPS. It features an 18*18mm RHCP ceramic patch antenna for superior reception and exceptional stability, as well as a QMC5883L high-precision magnetometer for pinpoint azimuth accuracy. Additionally, it is equipped with a u-blox10 generation chip to ensure smooth altitude shifts. This GPS is an ideal choice for FPV drones, multi-rotors, fixed wing aircraft, and other model products.

Check out our all ourFlight Controller Accessoriesand the rest of our Flyfishproducts!

Features:

• 72 channel 10 Hz Refresh rate
• Built-in TCXO crystal and farad capacitor for faster hot start
• High sensitivity 18x18mm GPS patch antenna
• SH1.0-6Pin terminal design, no soldering required.
• QMC5883L Magnetometer chip, Precise pointing

Specifications

• GPS module: FlyFishRC M8QMC-5883L GPS Module
• Frequencies: 72 channel
• Refresh Rate: 10 Hz
• Compass module: QMC5883L
• Baud Rate4800bps-115200bps (Default – 9600bps)
• Sensitivity: Tracking: -162dBm Capture: -160dBmCold Start-148dBm
• Accuracy: Horizontal <2.5m average), SBAS < 2.0m average, Timepulse: RMS 30 ns
• Cold start: <24s
• Hot start: <2s
• Maximum height: 50000m
• Maximum speed: 500 m/s
• Speed accuracy: 0.05 m/s
• Maximum acceleration: 4G
• Input Voltage: 3.3V-5Vcurrent 25mA
• Output Connector: SH1.0-6P
• Weight: 8.8g
• GPS pin definition: RX/TX UART
• Compass pin definition: SDA/SLA

Including

• 1 x FlyFishRC M8QMC-5883L GPS and Compass Module
• 1 x SH1.0-6Pin Cable
• 1 x SH1.0 Connector
• 1 x GPS Manual
