LiteRadio 3 Pro Radio TransmitterAn open-source radio remote control that supports the EdgeTX system. It comes with the hall gimbals, featuring four precision bearings, adjustable spring tension, and ergonomic stick ends for an unparalleled feel. The OLED display screen on the top of the transmitter brings visually instant data and a controlling interface to users. What’s more, two optional internal RF systems and alternative external nano TX module make it a multi-protocol transmitter.

Package Includes:

1x LiteRadio 3 Pro (ELRS 2.4)

Features:

• LiteRadio 3 Pro is a new milestone for LiteRadio Series so far. It is an open-source radio transmitter with the EdgeTX system.Therefore, you can try your best to customize it with the EdgeTx system.
• Hall gimbal features four precision bearings, adjustable spring tension, and ergonomic stick ends for an unparalleled feel.
• Built-in 2000mAh 1S battery, LiteRadio 3 Pro can work up to 15 hours without an external module, bringing an excellent endurance performance.
• A 1.3-inch OLED display screen is newly installed. Controlled by two 5D buttons and settings are easy to be adjusted directly from the display screen.
• Internal ELRS TX module up to 250mW output power enables LiteRadio 3 Proto excellently adapt its controlling range.
• Reserving a nano bay for an external TX module, it supports many popular modules in the market and meets all the protocols such as MULTI, CRSF, PPM, XJT, DSM2, R9M, etc. Highly recommendBETAFPV ELRS Nano TX Moduleand other brands of nano TX modules are also available.
• ExpressLRS 2.4G and CC2500 protocol options. The CC2500supportsCorona, Hitec, Futaba S-FHSS, Frsky D, X, RadioLink, Graupner HoTT, etc protocols.

EdgeTX Official Supported

LiteRadio 3 Pro Radio TransmitterAn open-source radio remote control that supports the EdgeTX system, which is an open-source firmware for RC radio transmitters. The firmware is highly configurable and brings much more features than traditional radios.Therefore, you can try your best to customize LiteRadio 3 Pro such as language, voice and etc with the EdgeTX system.

OLED Display Screen

OLED display screen with two 5D buttons is newly added to LiteRadio 3 Pro radio transmitter. Users can adjust the TX settings such as switching internal/external modules, gimbal calibration and binding on the screen by controlling 5D buttons. Compared withLiteRadio 3, it is easier to adjust such settings and very friendly to a new player.

EdgeTX Passthrough for ELRS Upgrade

With EdgeTX operating system,flashing ExpressLRS internal TX modules is easier for everyone. First, there is no need to disassemble the case. Compared with upgrading by WIFI, it is more convenient, fast, and stable to flash ELRS internal TX firmware by using EdgeTX passthrough flashing.

External TX Module

Nano module bay enables the external TX module available. LiteRadio 3 Pro reaches a high level with its capability to support multi-brand external TX modules in the market for different protocols such as MULTI, CRSF, PPM, XJT, DSM2, and R9M, etc.BETAFPV ELRS Nano TX Module, which features a high refresh rate, ultra-low latency, and long-range, is strongly recommended for LiteRadio 3 Pro.

Hall Gimbal

Features four precision bearings, adjustable spring tension, and ergonomic stick ends for an unparalleled feel. With an adjustable stick end, it perfectly fits thumbs and greatly improves the stick feel for the control. Hall Effect provides contactless sensing for not only accurate control inputs and precise centering but also durable use.

Switching Protocol and Binding

Radio transmitter settings and binding forELRS 2.4Gversion are shown below. Please turn on Internal and External RF protocol at the same time when using the internal ELRS TX module.(With ExperssLRS 2.4G sticker on the Nano module bay.)

• Set External RF modeon OFF.
• Turn on Internal RF and select CRSF mode.

• Binding: Enter the ExpressLRS.lua interface, and select Bind tocomplete linking.

Specifications:

Item: LiteRadio 3 Pro Radio Transmitter

Channel: 8 Channels

Gimbal: Hall Sensor

Frequency Range: 2.4G

RF System:SX1280 / CC2500

Antenna: Internal Antenna

RF Output Power: 50mW, 100mW, 250mW (ELRS 2.4G) / 100mW (CC2500)

Screen: 1.3 inch OLED display screen

Protocol Option: ExpressLRS 2.4G / CC2500 (Frsky D, Frsky X, SFHSS)

Battery: Built-in 2000mAh 1S Battery

Operating system: EdgeTX

Port: Type-C USB 3.0 port / 3.5mm Audio port

USB Support: Most Practice Simulator /USB charging /Firmware update / Passthrough (ELRS 2.4G)

Comparison Chart:
